GM LS Cylinder Head Cross Reference

We've tried to boil down the GM part numbers, casting numbers and other LS cylinder head information into an easily usable (and ideally definitive) cross reference.

Note that we're not perfect and some of this data may not be perfect so use it for what you will. That said we use much of this internally as we're applying our LS head porting profiles to customer heads and we'll update it accordingly as you give us feedback or we discover new oddities.

Cylinder Head GM Part Number Casting Numbers Intake Port Design Stock Deck Thickness
LS1 12564824
241
706
852
862
Cathedral 4.750" +- 0.003"
12564825
LS2 12562317
243
317
319
799
Cathedral 4.750" +- 0.003"
12562319
12629058
12572035
LS3 12629063

716
821
823
2716
5364

Rectangle 4.750" +- 0.003"
12604860
12629062
12615361
12629064
12711770
12675871
LS6 12564243 243 Cathedral 4.750" +- 0.003"
LS7 89017654 8452 Rectangle 5.039" +- 0.003"
12578450
LS9 12621773 Rectangle 4.750" +- 0.003"
LSA 12674063 863 Rectangle 4.750" +- 0.003"
12604861
12610716
12675872
  • New GM LSA CNC Ported Cylinder Heads - Set (12675872)-XtremeCFM-XCFM-10374
    New GM LSA CNC Ported Cylinder Heads - Set (12675872)
    $2,799.95
    $2,799.95
  • 6-Bolt LSX Cylinder Heads-XtremeCFM-XCFM-10460
